Magnum Vertex Ebike: Versatile Electric Bike | 27 MPH, 500W Motor

• The Vertex’s integrated and color-matched battery has a 15Ah capacity, and the ability to take a rider up to 50 miles on a single charge.
• 15Ah
• 50 miles (80 Kilometers) Max Range
• 7.5 Hours Charge Time

Power Meets Balance

• Throttle-controlled mid-drive motor
• Equipped with a powerful 500W mid-drive motor, this e-bike has natural power delivery, increased water resistance, and unique throttle control. It also features a derailleur clutch for rough terrain and a quick-detach rear wheel for easy maintenance.

Component Overview

Electronic Details

• Motor Brand: Ananda
• Motor Type: Mid-Drive Motor
• Motor Nominal Output: 500 Watts
• Motor Peak Output: 750 Watts
• Battery Brand: Samsung Cells
• Battery Voltage: 48 Volts
• Battery Ah: 15Ah
• Battery Wh: 720Wh
• Battery Chemistry: Li-NMC
• Battery Charge Time (from empty): 7.5 Hours
• Minimum Range: 25 Miles (40 Kilometers)
• Maximum Range: 50 miles (80 Kilometers)
• Display Type: Magnum Branded VeloFox, 8 x 7 cm, Backlit Monochrome LCD
• Display Readouts: Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time
• Drive Mode: Torque Sensor Pedal Assist, Thumb Throttle, Walk Mode
• Top Speed: Up to 28 mph with Pedal Assist, 20 mph with Throttle
• Lights: Integrated front light, saddle-mounted rear light

Measurements

• Seat Tube: 17.5″ (44 cm)
• Reach: 16″ (40.5 cm)
• Stand Over Height: 33″ (84 cm)
• Virtual Top Tube Length: 21″ (53 cm)
• Min Saddle Height: 21″ (53 cm)
• Max Saddle Height: 29.5″ (75 cm)
• Width: 28.5″ (72 cm)
• Wheelbase: 47.5″ (120.5 cm)
• Length: 76.25″ (193.5 cm)
• Total Weight: 74.5 lbs (33.75 kg)
• Battery Weight: 8.5 lbs (3.9 kg)
• Recommended Minimum Rider Height: 5’5″
